Is an Uni-directional Lug Type Valve Designed According To MSS-SP-81 For Industrial Service Applications. The Design Of The Body And Seat Assures Non-clogging Shut Off On Suspended Solids In Industries Such As:
Sizes: DN 50 to DN 1050 (larger diameters on request)
Working Pressure:
DN 50 to DN 400: 10 kg/cm² / 150 psi
DN 450 to DN 700: 4 kg/cm² / 60 psi
DN 700 to DN 1050: 2 kg/cm² / 45 psi
Standard Flange Connection:
TABLE "D", "E" DIN PN 10 and ANSI B16.5 (class 150)
Others on request
| PART | CAST IRON : STAINLESS STEEL LIST : |
|---|---|
| 1- BODY | C.I, WCB, CF8, CF8M, SGI |
| 2- GATE | AISI 304 AISI 316 |
| 3- SEAT | Metal To Metal (EPDM/VITON/PTFE/NITRIL) |
| 4- PACKING | PTFE Impreg. Synth. Fibre |
| 5- GLAND FOLLOWER | Ductile Iron, CF8, CF8M, WCB |
| 6- STEM | AISI 304 |
| 7- STEM NUT | Gun Metal |
| 8- YOKE | Carbon Steel |
| 9- SEAT RING | AISI 304 AISI 316 |
| 10- HANDWHEEL | Ductile Iron / Gjl 250 (gg25) |
| 11- FASTNERS | Zinc Plated Carbon Steel |
knife gate is an UNI-DIRECTIONAL / BI-DIRECTIONAL lug type valve designed according to MSS-SP-81 for industrial service applications. The design of the body and seat assures non-clogging shut off on suspended solids in industries such as:
Sizes: DN 50/2” to DN 400/16” (larger diameters on request)
Working Pressure:
DN 50/2” to DN 400/16”: 10 kg/cm² / 150 psi
Standard Flange Connection:
DIN PN 10 and ANSI B16.5 (class 150)
Others on
request
| PART | STAINLESS STEEL LIST |
|---|---|
| 1 - BODY | CF8, CF8M |
| 2 - GATE | AISI 304, AISI 316 |
| 3 - SEAT | METAL TO METAL (EPDM/VITON/PTFE/NITRIL) |
| 4 - PACKING | PTFE IMPREG. SYNTH. FIBRE |
| 5 - GLAND FOLLOWER | DUCTILE IRON CF8, CF8M, WCB |
| 6 - STEM | AISI 304 |
| 7 - STEM NUT | GUN METAL |
| 8 - YOKE | CARBON STEEL |
| 9 - SEAT RING | AISI 304, AISI 316 |
| 10 - OPERATED | PNEUMATIC / MANUAL / BEVEL GEAR |
| 11 - FASTNERS | ZINC PLATED CARBON STEEL |
This is a uni-directional lug type valve designed according to MSS-SP-81 for industrial service applications. The design of the body and seat assures non-clogging shut-off on suspended solids in industries such as:
Sizes: DN 50 to DN 1050 (larger diameters on request)
Working Pressure:
DN 50 to DN 400: 10 kg/cm² / 150 psi
DN 450 to 700: 4 kg/cm² / 60 psi
DN 700 to 1050: 3 kg/cm² / 45 psi
Standard Flange Connection:
TABLE "D", "E" DIN PN 10 and ANSI B16.5 (class 150)
Others on request
| PART | CAST IRON : STAINLESS STEEL LIST : |
|---|---|
| 1- BODY | C.I , WCB CFB, CF8M, SGI |
| 2- GATE | AISI 304 AISI 316 |
| 3- SEAT | Metal to Metal (EPDM/VITON/PTFE/NITRIL) |
| 4- PACKING | PTFE Impreg. Synth. Fibre |
| 5- GLAND FOLLOWER | Ductile Iron CF8, CF8M, WCB |
| 6- SOLENOID VALVE | 5/2 WAY (240VAC) (24VDC) |
| 7- LIMIT SWITCH | Mechanical, Proximity |
| 8- YOKE | Carbon Steel |
| 9- SEAT RING | AISI 304 AISI 316 |
| 10- PNEUMATIC | Cylinder Operated |
| 11- FASTNERS | Zinc Plated Carbon Steel |
This is a uni-directional lug type valve designed according to MSS-SP-81 for industrial service applications. The design of the body and seat assures non-clogging shut-off on suspended solids in industries such as:
Sizes: DN 50 to DN 1050 (larger diameters on request)
Working Pressure:
DN 50 to DN 400: 10 kg/cm² / 150 psi
DN 450 to 700: 4 kg/cm² / 60 psi
DN 700 to 1050: 3 kg/cm² / 45 psi
Standard Flange Connection:
TABLE "D", "E" DIN PN 10 and ANSI B16.5 (class 150)
Others on request
| PART | CAST IRON : STAINLESS STEEL LIST : |
|---|---|
| 1- BODY | C.I , WCB CFB, CF8M |
| 2- GATE | AISI 304 AISI 316 |
| 3- SEAT | Metal to Metal (EPDM/VITON/PTFE/NITRIL) |
| 4- PACKING | PTFE Impreg. Synth. Fibre |
| 5- GLAND FOLLOWER | Ductile Iron CF8, CF8M, WCB |
| 6- STEM | AISI 304 |
| 7- NUT | Gun Metal |
| 8- YOKE | Carbon Steel |
| 9- SEAT RING | AISI 304 AISI 316 |
| 10- BEVEL GEAR | Manual Operated |
| 11- FASTNERS | Zinc Plated Carbon Steel |
Is an Uni-directional Lug Type Valve Designed According To MSS-SP-81 For Industrial Service Applications. The Design Of The Body And Seat Assures Non-clogging Shut Off On Suspended Solids In Industries Such As:
Sizes: DN 50 to DN 1050 (larger diameters on request)
Working Pressure:
DN 50 to DN 400: 10 kg/cm² / 150 psi
DN 450 to 700: 4 kg/cm² / 60 psi
DN 700 to 1050: 2 kg/cm² / 45 psi
Standard Flange Connection:
TABLE "D", "E" DIN PN 10 and ANSI B16.5 (class 150)
Others on request
| PART | CAST IRON : STAINLESS STEEL LIST : |
|---|---|
| 1- BODY | C.I, WCB, CF8, CF8M, SGI |
| 2- GATE | AISI 304 AISI 316 |
| 3- SEAT | Metal To Metal (EPDM/VITON/PTFE/NITRIL) |
| 4- PACKING | PTFE Impreg. Synth. Fibre |
| 5- GLAND FOLLOWER | Ductile Iron, CF8, CF8M, WCB |
| 6- STEM | AISI 304 |
| 7- STEM NUT | Gun Metal |
| 8- YOKE | Carbon Steel |
| 9- SEAT RING | AISI 304 AISI 316 |
| 10- HANDWHEEL | Ductile Iron / Gjl 250 (gg25) |
| 11- FASTNERS | Zinc Plated Carbon Steel |
This is a uni-directional lug type valve designed according to MSS-SP-81 for industrial service applications. The design of the body and seat assures non-clogging shut-off on suspended solids in industries such as:
Sizes: DN 50 to DN 1050 (larger diameters on request)
Working Pressure:
DN 50 to DN 400: 10 kg/cm² / 150 psi
DN 450 to 700: 4 kg/cm² / 60 psi
DN 700 to 1050: 3 kg/cm² / 45 psi
Standard Flange Connection:
TABLE "D", "E" DIN PN 10 and ANSI B16.5 (class 150)
Others on request
| PART | CAST IRON : STAINLESS STEEL LIST : |
|---|---|
| 1- BODY | C.I , WCB CFB, CF8M |
| 2- GATE | AISI 304 AISI 316 |
| 3- SEAT | Metal to Metal (EPDM/VITON/PTFE/NITRIL) |
| 4- PACKING | PTFE Impreg. Synth. Fibre |
| 5- GLAND FOLLOWER | Ductile Iron CF8, CF8M, WCB |
| 6- STEM | AISI 304 |
| 7- STEM NUT | Gun Metal |
| 8- YOKE | Carbon Steel |
| 9- SEAT RING | AISI 304 AISI 316 |
| 10- OPERATOR | Chain Wheel |
| 11- FASTNERS | Zinc Plated Carbon Steel |
